Three Phase Hybrid Inverter DEYE SUN-30K-SG01HP3-EU-BM3 30kW
4,338.34 €
All prices are quoted excluding VAT and do not include delivery costs
The product is available for order in Montenegro, Serbia, Croatia, Slovenia, Germany
Гарантия 10 лет
Description
- 100% unbalanced output, each phase; Max. output up to 50% rated power
- DC couple and AC couple to retrofit existing solar system
- Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
- Max. charging/discharging current of 100A
- High voltage battery, higher efficiency
- 6 time periods for battery charging/discharging
- Support storing energy from diesel generator
| Battery Input Data | |
| Battery Type | Lithium-ion |
| Battery Voltage Range (V) | 160~800 |
| Max. Charging Current (A) | 50A+50A |
| Max. Discharging Current (A) | 50A+50A |
| Number of battery input | 2 |
| Charging Strategy for Li-Ion Battery | Self-adaption to BMS |
| PV String Input Data | |
| Max. DC Input Power (W) | 39000W |
| Rated PV Input Voltage (V) | 1000 |
| Start-up Voltage (V) | 250V |
| MPPT Range (V) | 150~850V |
| Min. DC Input Voltage (V) | 150V |
| Full Load DC Voltage Range (V) | 360-850V |
| Rated DC Input Voltage (V) | 600V |
| PV Input Current (A) | 36A+36A+36A |
| Max. PV ISC (A) | 55A+55A+55A |
| No.of MPPT Trackers | 3 |
| No.of Strings Per MPPT Tracker | 2 |
| AC Output Data | |
| Rated AC Output and UPS Power (W) | 30000W |
| Max. AC Output Power (W) | 33000W |
| AC Output Rated Current (A) | 45.6 |
| Max. AC Current (A) | 60 |
| Max. Continuous AC Passthrough (A) | 150A |
| Peak Power (off grid) | 1.5 times of rated power, 10 S |
| Generator input/Smartload /AC couple current(A) | 45.6 / 150 / 45.6 |
| Power Factor | 0.8 leading to 0.8 lagging |
| Output Frequency and Voltage | 50/60Hz; 3L/N/PE 220/380, 230/400Vac |
| Grid Type | Three Phase |
| DC injection current (mA) | <0.5% 1n |
| Efficiency | |
| Max. Efficiency | 97.60% |
| Euro Efficiency | 97.00% |
| MPPT Efficiency | 99.90% |
| Protection | |
| PV Input Lightning Protection | Integrated |
| Anti-islanding Protection | Integrated |
| PV String Input Reverse Polarity Protection | Integrated |
| Insulation Resistor Detection | Integrated |
| Residual Current Monitoring Unit | Integrated |
| Output Over Current Protection | Integrated |
| Output Shorted Protection | Integrated |
| Output Over Voltage Protection | DC Type II/AC TypeIII |
| Surge protection | Integrated |
| Certifications and Standards | |
| Grid Regulation | CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98, VDE 0126-1-1, RD 1699, C10-11 |
| Safety EMC / Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
| General Data | |
| Operating Temperature Range (℃) | -40~60℃, >45℃ Derating |
| Cooling | Smart cooling |
| Noise (dB) | <45 dB |
| Communication with BMS | RS485; CAN |
| Weight (kg) | 60 |
| Size (mm) | 560.5W×837H×319D |
| Protection Degree | IP65 |
| Installation Style | Wall-mounted |
| Warranty | 10 years |
Additional information
| Weight | 96.50000 kg |
|---|---|
| AC output power, kW | |
| Phase type | 3-phase |
| Inverter type | Hybrid |
| Battery type | High voltage (HV) |
| Number of MPPT | 3 |
