Hybrid inverter DEYE SUN-10K-SG05LP3-EU-SM2 10 kW, 3-phase, LV, 5th generation
2,159.21 €
Three-phase hybrid inverter DEYE SUN-10K 5th generation with wall bracket. Asymmetric output of 0–5 kW per phase.
All prices are quoted excluding VAT and do not include delivery costs
The product is available for order in Montenegro, Serbia, Croatia, Slovenia, Germany
Гарантия 5.0 лет
Description
The universal low-voltage 3-phase hybrid inverter Deye SUN-10K 5th generation with wall mounting combines a solar inverter and a battery charger. It supports an asymmetric 3-phase output with a range of 0 to 5 kW per phase, with the ability to overload by 100% for 10 seconds, which expands application scenarios to the absolute maximum. The inverter is compatible with low-voltage batteries from 40 to 60V. Communication with the BMS is carried out via CAN or RS485 interface and is fully compatible with the latest models of batteries from other brands. The color LCD display provides a convenient interface for system overview and configuration (battery management, AC/solar charging depending on various applications, etc.). The main advantage of this inverter is the configurable input/output “smart load,” where a generator, string inverter, or water heater can be connected for heating water. The capabilities of this port allow for similar functions as a wattrouter.
This inverter has successfully passed PPDS certification in categories A1 and A2 on 24.09.2025 at the Clean Energy Laboratory, EG.D in České Budějovice. Based on these certifications, it can be permanently connected to the distribution network in the Czech Republic according to the regulations effective from 1.01.2025.
Key Features
- Supports 3-phase asymmetric output
- Number of MPP trackers: 2 inputs (2+2)
- MPPT voltage range: 200 to 650 V
- High charging and discharging current: 210 A
- Communication interface: CAN/RS-485 (for BMS), Modbus (RTU 485, e.g., for Loxone or external control systems), RS-232 (for cloud dongle)
- Intelligent Solarman monitoring platform for managing solar power plants. Can be equipped with a communication interface via Wi-Fi (included), Ethernet, or LTE.
- Unique Smart Load feature, Grid peak shaving, phase balancing
- IP65 protection rating
10-Year Warranty
During the first five years, the warranty covers all parts, including labor. During the second five-year period, the warranty covers all parts except for the LCD, fan, and labor. Detailed information about the 10-year warranty from DEYE can be found here.
Package Contents
- Hybrid inverter
- Wall mounting
- 4x concrete anchors
- 3x measuring coil 100 A / 50 mA
- Temperature sensor for Pb batteries
- Wi-Fi dongle
Additional information
| Weight | 43.500 kg |
|---|---|
| Inverter type | Hybrid |
| Battery type | Low voltage (LV) |
| Number of MPPT | 2 |
| Phase type | 3-phase |
| AC output power, kW |
About Brands
About Deye
Ningbo Deye Inverter Technology Co., Ltd. founded in 2007 with a registered capital of 300 million RMB, is one of China’s high-tech enterprises and a subsidiary of Deye Group. With a plant area of over 15,000㎡ and complete production and testing equipment, Deye has become a major player in the global solar inverter market.
Ningbo Deye Inverter Technology Co., Ltd. is dedicated to providing complete photovoltaic power system solutions, including residential and commercial power plant solutions.
Also, Deye offers the right device for each application: for all module types, for grid connection and stand-alone grids as well as hybrid inverter systems, for small house systems and commercial systems in the Megawatt range. Among them, PV grid-connected inverter power ranges from 1-136kW, Hybrid inverter 3kW-50kW, and microinverter 300W-2000W.
